Roller Sliding Table, XY Linear Stage, Linear Sliding Table, M2GS60 Manual XY Roller Sliding Table, Linear Roller Bearings

1. Stainless steel material, anti-wear and waterproof, to and oxidation, higher accuracy and more stable.2. mechanical structure design offers stable work performance and high load‑bearing capacity.3. Features large stroke and high displacement accuracy, convenient to use, which has strong practicality.4. Useful mechanical device, which can provide linear motion for equipment, high dependability.5. roller type, 60μm parallelism, ±6.5mm micrometer movement and feed screw movement.Spec:Condition: Brand NewItem Type: Linear Sliding TableMaterial: Stainless SteelModel: -S60Purpose: A mechanical device that can provide linear motion for equipmentMicrometer Movement: ±6.5mmFeed Screw Movement: ±6.5mmSliding Table: Approx. 60 x 60mm/2.4 x 2.4inWithstand Load: 44.1NMovement Accuracy:Straightness: 3μmParallelism: 20μmMovement Accuracy:Swing Up And Down 25 SecondSwing Left And Right: 15 SecondAllowable Moment Load:Swing Up And Down 5.2N·MShake Left And Right 4.3N·MSide Rolling 5.2N·MMoment Rigidity:Swing Up And Down 0.19 Second/N·CmShake Left And Right 0.22 Second/N·CmSide Roll 0.19 Second/N·CmParallelism: 60μmRail Type: Rollerpacking list:1 x Sliding Table

• [ roller type]--This micrometer trimming is a roller type, with large stroke, high displacement accuracy, and strong practicability. It can provide linear motion for equipment.
• [Linear Sliding Table]--micrometer movement: ±6.5mm; feed screw movement: ±6.5mm; action accuracy: straightness: 3μm, parallelism: 20μm; rail type: roller
• Easy to use
• [Excellent performance]--XY linear sliding table is made of stainless steel, which is more wear-resistant, waterproof, and oxidation-resistant, with higher precision and more stability.
• [High bearing capacity]--The mechanical structure design of Manual XY linear stage can provide stable working performance and high bearing capacity, and its bearing load is 44.1N.
